SBH - Android 01
Model no. : SBH-Android/01
Introducing our latest product line : the SBH-Android/n series.
Reducing waiting time and facilitating faster scanning of items & quicker payments, our Android POS is here to make life easy and at the same time technologically advanced for customers and enterprises alike.
Dimensions:
390g – including battery
Weight:
182.50mm(L) x 78mm (W) x 25mm (D)
Operating/Storage Temperature:
-10℃ to 50℃ / -20℃ to 60℃
Relative Humidity:
10% to 90% RH (Non-condensation)
CPU:
Quad-core 1.1GHz
OS:
Android 5.1/9.x
Memory:
RAM 1GB DDR3, ROM 8GB eMMC (Default)
RAM 2GB DDR3, ROM 16GB Emmc (Optional)
Support 32GB External TF card at most
RAM 2GB DDR3, ROM 16GB Emmc (Optional)
Support 32GB External TF card at most
Touch Screen:
5 inch 1280 x 720 HD
Keypad:
1 x Power Key, 3 x in-screen touch key (Menu, Back, Home)
Battery:
7.4V 2000mAh (Default)
Adapter:
Input : 100 -240V AC, 50Hz / 60Hz, Output : 5V/2A
Camera:
2M Pixel Read Camera, Flash LED, Reads 1D & 2D Codes
Indicator LED:
1 x Charging Indicator LED, 4x NFC Indicator LED
Audio:
1 x Built-in speaker
Contactless Card Reader:
13.56MHz, ISO/IEC 14443 Type A/B
Printer:
2-inch 7.4V Thermal Printer
Paper Width : 58mm, Diameter : 40mm
Paper Width : 58mm, Diameter : 40mm
Card Slots:
1 SIM Slot & 2PSAM Slots (Default)
2SIM Slot & 1PSAM Slot (Optional)
1 TF card slot
2SIM Slot & 1PSAM Slot (Optional)
1 TF card slot
Pin Pad:
Touch Screen
Network type:
4G (FDD-LTE/TDD-LTE) +3G(WCDMA) + 2G(GSM) (Optional)
WLAN:
2.4G, 802.11b/g/n Inner Antenna
Navigation:
GPS, support AGPS
Bluetooth:
Bluetooth v4.0 + EDR
USB Interface:
1 Micro USB 2.0
Charge JACK:
1 DC JACK 3.5mm
POGO PIN:
5V—2A
Multifunctional Docking Base (Optional):
Ports (2 x Type-A HOST USB 2.0,1 X RJ45 (Serial Port), 1 x RJ45 (LAN), 1 x DC 3.5mm Port), POGO Pins Interface, Scanner Window, 1 x LED Power Indicator, 1 x LED communication indicator
Development Environment Management Software:
SaiBalaji –SDK
SaiBalaji – PC MDM
SaiBalaji – PC MDM
Compliance:
CE, RoHs, FCC
